Home > Mortise Lock Systems > Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System
1 / 5
Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System
Cm3 Access Control Devices Door Access Card System Badge Access Control System

Cm3 Access Control Devices Door Access Card System Badge Access Control System

Customization: Available
After-sales Service: Technical Support & Customization Service
Warranty: 1
Send Inquiry

Product Description

📋 Basic Information
Model NO.
CM3
Material
Aluminum Alloy
Type
Combination Lock
Style
European
Shape
Mortise Door Lock
Anti-theft Standard
A
Backset
70mm
Power
3V, 4 * Battery
BLE Wireless
BLE 5.3 Master & Slave, Zigbe
Interface
WiFi, BLE 5.3, USB
🔍 Product Overview
Smart CM3 is the new generation of BLE 5.4 wireless high-performance multi-technology platform. It provides an ultra-low battery-operated power consumption design, which contains the latest wireless interfacing and multiple identification technologies for customized design of access control, wireless electric lock, canteen management, asset tracking and different handheld applications.

Smart CM3 supports almost all RFID 13.56MHz contactless technologies, including DESFire EV1/EV2/EV3. It also supports NFC and BLE Mobile credentials for mobile applications. Together with supporting Arm® TrustZone® and securable I/Os features, it meets high security application requirements.
Smart CM3 Overview
⭐ Key Features & Advantages
✔ Support 13.56MHz Desfire EV1/EV2/EV3 and NFC
✔ Support Arm® TrustZone® for high security
✔ Rich I/O port for electric lock control
✔ Economic solution for battery powered ultra-low power consumption
✔ Supports BLE 5.4 Zigbee, Thread/Matter/MQTT protocol
✔ Body detection function and local data storage
CM3 Features 1
CM3 Features 2
CM3 Features 3
⚙ Technical Specifications
Parameter Details
Memory4M BYTE
Power SupplyUSB or 3V / 4 * battery
RFID Standards13.56MHz ISO14443A, ISO15693, ISO18092 (Mifare, DESfire EV1/2/3, NFC Tag, HID iCLASS CSN)
Secure InterfaceOptional SAM slot ISO7816; Secure IC for MCU protection EAL5+ Level
Mobile CommunicationNFC, BLE 5.3
Keypad12 digit mechanical keypad
InterfacesWiFi, BLE 5.3 (Master/Slave, Beacon, Thread, Zigbee, Mesh), USB
IndicatorsBuzzer and Bio-color LED
Input/OutputGPI/O * 8
Operating Temp-20ºC ~ 60ºC
CM3 Specifications Diagram
📖 System Capabilities
System Capabilities Overview
❓ Frequently Asked Questions
What wireless technologies does the Smart CM3 platform support?
The CM3 supports BLE 5.3/5.4, WiFi, Zigbee, Thread, Matter, and MQTT protocols for versatile wireless connectivity.
Which RFID card types are compatible with this device?
It supports 13.56MHz contactless technologies including Mifare Classic, DESFire EV1/EV2/EV3, Ultralight, NFC tags, and HID iCLASS CSN.
How is the device powered?
The system can be powered via a USB connection or through a 3V battery setup (4 * batteries), designed for ultra-low power consumption.
What level of security does the CM3 provide?
It integrates Arm® TrustZone® and features a Secure IC for MCU communication protection at the EAL5+ level.
Can the device be used in extreme temperatures?
Yes, the CM3 is designed to operate reliably within a temperature range of -20ºC to 60ºC.
Does it support mobile access credentials?
Absolutely. It supports both NFC mobile phone interaction and BLE 5.3 for mobile-based access control.
