Customization: Available
After-sales Service: Technical Support & Customization Service
Warranty: 1
Send Inquiry

Product Description

Basic Information
Model NO.
CM3
Material
Aluminum Alloy
Type
Combination Lock
Style
European
Shape
Mortise Door Lock
Anti-theft Standard
A
Part
Lock
Backset
70mm
Usage
Household Door Locks, Bedroom, Channel Lock
RFID
MIFARE Plus, MIFARE, DESFire EV1/EV2, ISO14443b
Secure Interface
Sam Slot & Secure IC Eal5+ Level
BLE Wireless
BLE 5.3 Master & Slave Mode, Beacon, Thread, Zigbee
Communication
WiFi, BLE 5.3, USB
Keypad
12 Digit Keypad
Power
3V, 4 * Battery
Capacity
1000PCS/Month
Product Overview
Smart CM3 is the new generation of BLE 5.4 wireless high-performance multi-technology platform. It provides an ultra-low battery-operated power consumption design, which contains the latest wireless interfacing and multiple identification technologies for customized design of access control, wireless electric lock, canteen management, asset tracking, and different handheld applications.
Smart CM3 supports almost all RFID 13.56MHz contactless technologies, including DESFire EV1/EV2/EV3. It also supports NFC and BLE Mobile credentials for mobile applications. Together with supporting Arm® TrustZone® and securable I/Os features, it meets high-security application requirements.
Smart CM3 Product Overview
Product Features
Feature 1
Feature 2
Feature 3
Advantages
  • Support 13.56MHz DESFire EV1/EV2/EV3 and NFC
  • Support Arm® TrustZone® for high security
  • Rich I/O port for electric lock control
  • With memory for local data storage
  • Economic solution for battery powered ultra-low power consumption reader
  • Supports BLE 5.4 Zigbee, Thread/Matter/MQTT protocol
  • Embedded software development
  • With Body detection function
Advantages Visualization
Specifications
Memory 4M BYTE
Power Supply USB / 3V (4 * battery)
RFID Standards 13.56MHz ISO14443A, ISO15693, ISO18092; Mifare Classic, DESFire EV1/EV2/EV3, Ultralight C, Mifare Plus, NFC tag, HID iCLASS CSN
Secure Interface Optional SAM slot ISO7816; SAM AV2 for encryption; Secure IC for MCU protection EAL5+ Level
Mobile Comm. NFC mobile phone, BLE 5.3
Keypad 12 digit mechanical keypad
Interfaces WiFi, BLE 5.3 (Master & Slave, Beacon, Thread, Zigbee, Mesh), USB
Indicators Buzzer and Bio-color LED
Input/Output GPI/O * 8
Operating Temp -20ºC ~ 60ºC
Configuration Configuration card, reader tool software or factory configured readers
About Our Technology
Technology and Production
Frequently Asked Questions
Q1: What types of RFID cards are compatible with the Smart CM3?
A: It supports a wide range of 13.56MHz technologies including Mifare Classic, DESFire EV1/EV2/EV3, Ultralight, Mifare Plus, and NFC tags.
Q2: Does the device support mobile phone access?
A: Yes, it supports both NFC mobile phone communication and BLE 5.3/5.4 for mobile credentials.
Q3: How is the CM3 powered?
A: The device can be powered via a USB connection or by a 3V battery setup (typically 4 batteries), designed for ultra-low power consumption.
Q4: What wireless protocols are supported for integration?
A: It supports BLE 5.3/5.4, WiFi, Zigbee, Thread, Matter, and MQTT protocols for versatile wireless connectivity.
Q5: Is the system secure against hacking?
A: Yes, it features Arm® TrustZone® technology, secure I/Os, and an optional SAM slot with EAL5+ level encryption for high-security applications.
Q6: What is the operating temperature range?
A: The Smart CM3 is designed to operate reliably in temperatures ranging from -20ºC to 60ºC.
