Customization: Available
After-sales Service: Technical Support & Customization Service
Warranty: 1
Send Inquiry

Product Description

Basic Information
Model NO.
CM3
Material
Aluminum Alloy
Type
Combination Lock
Style
European
Shape
Mortise Door Lock
Anti-theft Standard
A
Part
Lock
Backset
70mm
Usage
Household Door Locks, Bedroom, Channel Lock
RFID
MIFARE Plus, MIFARE, DESFire EV1/EV2, ISO14443b
Communication
WiFi, BLE 5.3, USB
Origin
China
Product Overview
Smart CM3 is the new generation of BLE 5.4 wireless high-performance multi technology platform. It provides an ultra-low battery operated power consumption design, which contain the latest wireless interfacing and multiple identification technologies for customized design of access control, wireless electric lock, canteen management, asset tracking and different handheld applications.

Smart CM3 supports almost all RFID 13.56MHz contactless technologies, including desfire EV1/EV2/EV3. It also supports NFC and BLE Mobile credentials for mobile application. Together with supporting Arm® TrustZone® and securable I/Os features, it meet the high security application.
Smart CM3 Identity Platform
Product Features
Feature 1
Feature 2
Feature 3
Key Advantages
✓
Support 13.56MHz Desfire EV1/EV2/EV3 and NFC
✓
Support Arm® TrustZone® for high security
✓
Rich I/O port for electric lock control
✓
With memory for local data storage (4M BYTE)
✓
Economic solution for battery powered ultra-low power consumption reader
✓
Supports BLE 5.4 Zigbee, Thread/Matter/MQTT protocol
Advantages Diagram
Specifications
Memory 4M BYTE
Power Supply USB / 3V (4 * battery)
RFID Standards 13.56MHz ISO14443A, ISO15693, ISO18092; Mifare Classic/Plus, DESfire EV1/EV2/EV3, Ultralight, NFC, HID iCLASS
Secure Interface Optional SAM slot (ISO7816); Secure IC for MCU protection (EAL5+ Level)
Mobile Comm NFC mobile phone, BLE 5.3
Keypad 12 digit mechanical keypad
Interfaces WiFi, BLE 5.3 (Master & Slave, Mesh, Zigbee), USB
Indicators Buzzer and Bio-color LED
Operating Temp -20ºC ~ 60ºC
About Us
Production and Capability
Frequently Asked Questions
Q1: What makes the CM3 platform energy efficient?
The Smart CM3 is designed with the latest BLE 5.4 technology, providing ultra-low battery-operated power consumption, making it ideal for wireless electric locks.
Q2: Which RFID card types are compatible with this system?
It supports a wide range of 13.56MHz technologies including DESfire EV1/EV2/EV3, Mifare Classic, Mifare Plus, Ultralight, and HID iCLASS.
Q3: Can I use my smartphone for access?
Yes, the CM3 supports both NFC and BLE Mobile credentials, allowing users to use mobile phones for identification.
Q4: What level of security does the CM3 offer?
It features Arm® TrustZone® support and Secure IC for MCU communication protection at an EAL5+ Level.
Q5: What are the available communication interfaces?
The platform offers multiple interfaces including WiFi, BLE 5.3 (supporting Mesh, Zigbee, and Thread), and USB.
Q6: What is the operating temperature range?
The device is designed to operate reliably in temperatures ranging from -20ºC to 60ºC.
