Customization: Available
After-sales Service: Technical Support & Customization Service
Warranty: 1
Send Inquiry

Product Description

Basic Information
Model NO.
CM3
Material
Aluminum Alloy
Type
Combination Lock
Style
European
Shape
Mortise Door Lock
Anti-theft Standard
A
Backset
70mm
Communication
WiFi, BLE 5.3, USB
Keypad
12 Digit Mechanical
Power
3V, 4 * Battery
Product Overview
Smart CM3 is the new generation of BLE 5.4 wireless high-performance multi-technology platform. It provides an ultra-low battery-operated power consumption design, which contains the latest wireless interfacing and multiple identification technologies for customized design of access control, wireless electric lock, canteen management, asset tracking, and different handheld applications.
Smart CM3 supports almost all RFID 13.56MHz contactless technologies, including DESFire EV1/EV2/EV3. It also supports NFC and BLE Mobile credentials for mobile applications. Together with supporting Arm® TrustZone® and securable I/Os features, it meets high-security application requirements.
Smart CM3 Overview
Product Features
Feature 1
Feature 2
Feature 3
Key Advantages
  • Support 13.56MHz DESFire EV1/EV2/EV3 and NFC
  • Support Arm® TrustZone® for high security
  • Rich I/O port for electric lock control
  • Economic solution for battery powered ultra-low power consumption
  • Supports BLE 5.4, Zigbee, Thread/Matter/MQTT protocols
  • Built-in Body detection function
Advantages Visualization
Technical Specifications
Memory 4M BYTE
Power Supply USB or 3V (4 * battery)
RFID Standards 13.56MHz ISO14443A, ISO15693, ISO18092; Mifare Classic, DESFire EV1/EV2/EV3, Ultralight C, Plus S/X, NFC tag, HID iCLASS CSN
Secure Interface Optional SAM slot ISO7816; SAM AV2 support; Secure IC EAL5+ Level
Mobile Comm. NFC mobile phone, BLE 5.3
Interfaces WiFi, BLE 5.3 (Master & Slave, Beacon, Thread, Zigbee, Mesh), USB
Indicators Buzzer and Bio-color LED
Operating Temp. -20ºC ~ 60ºC
Manufacturing Excellence
Production Facility
Frequently Asked Questions
What wireless protocols does the CM3 support?
The Smart CM3 supports a wide range of protocols including BLE 5.3/5.4, WiFi, Zigbee, Thread, Matter, and MQTT, making it highly versatile for IoT applications.
Is the device suitable for battery-powered applications?
Yes, it is specifically designed for ultra-low power consumption, operating on a 3V system (4 * batteries), ideal for wireless electric locks and handheld devices.
Which RFID technologies are compatible with this reader?
It supports almost all 13.56MHz technologies, including Mifare Classic, DESFire EV1/EV2/EV3, Ultralight, Plus S/X, and HID iCLASS CSN.
How does the CM3 ensure data security?
Security is handled via Arm® TrustZone® technology, optional SAM slots with EAL5+ encryption, and secure ICs for MCU communication protection.
Can I use my smartphone to interact with the lock?
Absolutely. The CM3 supports both NFC and BLE 5.3 mobile credentials, allowing for seamless mobile-based access control.
What is the operating temperature range for the CM3?
The device is designed to operate reliably in environments ranging from -20ºC to 60ºC.
